HOPPE New York PSK Manual Sliding Patio Door Handle 40mm White RAL 9016 per piece

Product

Handle designed for manual parallel sliding doors, the Hoppe New-York PSK is suitable for residential and commercial applications requiring functional and aesthetic hardware. Finished in white RAL 9016, it fits 40 mm systems for smooth door operation.

Specifications

• Solid HOPPE 40 mm spindle, polyamide sub-base, and concealed M5 screw fixing.
• Certified to DIN EN 13126-3: 23/180-0150/03/C1 and RAL-GZ 607/9 standards for durability and performance.
• Features 90° notched positioning, removable cover cap, and robust mounting pillars.

Usage

Attach the handle directly to the sliding sash using the supplied concealed fixings. The 90° notching offers defined stop positions, ensuring smooth and secure operation. The removable cover facilitates maintenance and installation.

FAQ

1. Is this handle compatible with all sliding doors?
   It is designed specifically for manual parallel sliding doors with a 40 mm profile; check system compatibility before installation.

2. What certifications does this handle meet?
   It is certified according to DIN EN 13126-3: 23/180-0150/03/C1 and RAL-GZ 607/9 for safety and reliability.

3. How is the handle installed?
   Fixing is concealed and uses M5 threaded screws, supported by mounting pillars and a polyamide sub-base for stability.

4. Does the handle have defined locking positions?
   Yes, it features crantage at 90°, providing a secure stop-in position during use.

5. Can the cover cap be removed for maintenance?
   The removable cover cap enables straightforward maintenance and access to the fixing components.
