Usage
This kit is designed for assembling or repairing drawers with 86mm high sides, featuring white metal sides and runners suitable for furniture, cabinetry, or storage solutions in homes and workplaces.
Advantages
- Provides a robust metal structure with durable epoxy-coated white finish for added longevity and easy cleaning[1][6].
- Self-closing mechanism enhances user convenience by ensuring drawers return smoothly to the closed position[1].
- Supports loads up to 25kg, suitable for everyday storage needs in residential or commercial settings[1].
- Screw-on installation facilitates a straightforward assembly process even during retrofits[1][5].
- White color integrates seamlessly with modern cabinetry designs.
Specifications
- The system uses epoxy-coated steel sides (white) paired with sturdy metal runners; suitable for drawer depths up to 350mm[1].
- The finish provides resistance against corrosion and wear; the drawer kit supports daily use over an extended period[1][6].
- Bearing capacity: maximum load of up to 25kg per drawer; side height: 86mm; compatible runner length: up to 350mm[1].
- Differentiating features include a self-closing function, double stop positions, two-dimensional front adjustment capability, and compatibility with screw-on bottoms or optional dowels for flexible mounting options[1][5].
How it works
This kit includes two pre-finished metal sides (86mm high) and matching runners. Attach the bottom panel (not included), mount the runners into your cabinet at the desired depth (up to 350mm), then install the assembled drawer. The integrated self-closing feature guides the drawer smoothly shut each time you close it.[1]
