Modular multipoint lock DECENA lever handle with 2 rollers F18 50 70 2400mm per piece

Product

Modular multipoint lock system by Ferco, designed for secure residential or commercial doors. Features 2 rollers for enhanced locking, a handle-operated mechanism, and is suitable for reversible installation on various door types.

Specifications

• Flat faceplate: 18 mm width, thickness 3 mm
• 50 mm center distance, reversible for left or right-hand doors
• Central case with day latch and half-turn functionality
• Total length: 2150 mm
• Bichromated finish for corrosion resistance
• Kit includes: 1 main espagnolettes (1522 mm), 2 extensions (423 mm each with a roller), 1 additional extension (250 mm)
• Modular design allows for flexible door height adaptation

Usage

The lock is installed vertically along the door edge, with multiple points engaging into the frame when operated by the handle. The modular extensions accommodate doors of varying heights, while rollers ensure smooth engagement and added security during closure.

FAQ

1. What door types are compatible with this lock?

   • Suitable for both left and right-handed doors, with modular extensions for flexible height adjustment.

2. How is the lock operated?

   • Operated by a handle that simultaneously engages the central latch and multi-point rollers.

3. Is professional installation required?

   • Recommended for optimal performance and to ensure correct alignment with the door and frame.

4. What materials is the lock made from?

   • The lock features a flat steel faceplate with a durable bichromated finish for corrosion resistance.

5. Are spare parts or extensions available?

   • The modular system includes additional extension parts, and compatible replacements can be sourced from Ferco’s range.
