Usage
The laquered black Raccord de compas is designed for mechanically joining and securing ROTO ALU 540i hardware components in windows and doors made of wood, PVC, or aluminium. It ensures stable linkage within tilt-and-turn or opening systems.
Advantages
- Compatible with ROTO ALU 540i systems for aluminium, wood, and PVC profiles
- Durable black lacquered finish (RAL 9005) provides aesthetic integration with modern window frames
- Simplified installation due to preassembled clamp-strips and modular design[1]
- Non-handed design allows flexible use on either side of the sash[1][2]
- Lateral and vertical adjustment possible while installed for precise positioning[1]
Specifications
- Lacquered steel component; color: black RAL 9005; matches other fittings in the system[1][9]
- Suits sashes up to a maximum weight of approximately 80–130 kg depending on configuration[1][9]
- Cyclic tested for durability; maintains performance over thousands of operational cycles (in line with European standards)[5]
- Flush mounting with no visible screws enhances appearance; reduces number of parts required by integrating stay-bearing pin retention
How it works
The fitting is attached to the window or door sash using supplied fasteners. It joins mechanical parts within the tilt-and-turn mechanism, ensuring secure movement and reliable connection between frame elements. Adjustment can be performed after installation without disassembly.[3][4][9]
