Product
Cylindrical drill-in hinge, 14 mm diameter, ideal for a range of door applications including swing doors, folding doors, flaps, and chest lids. Designed for invisible installation, maintaining a clean and modern hardware finish.
Specifications
- Solid brass construction with a brushed matte finish
- Opening angle: 180°
- Designed for 14 mm bore diameter
- Suitable for light to moderate door systems
- Not visible when the door is closed
Usage
Drill a 14 mm hole in the frontal side of the casing. Insert the cylindrical hinge — with or without adhesive — into the bore, then secure using the expansion screws. This system provides reliable, discreet pivoting for non-load-bearing doors and panels.
FAQ
- What door thickness is required?
The hinge is suitable for materials with a minimum thickness of 19 mm (3/4"). - Can this hinge be used for heavy doors?
No, it is recommended for light to moderate doors; not suitable for load-bearing or heavy-duty vertical use. - Is the installation hardware included?
Installation screws are included; a 14 mm drill bit is required for proper bore sizing. - What is the maximum opening angle?
The hinge allows for a 180° door opening. - Is the hinge visible when the door is closed?
No, the hinge remains completely concealed when the door or lid is shut.
