Usage
The Litto B1112 surface-mounted lock is designed for securing wooden doors and gates in residential or light commercial settings. Suitable for both interior and exterior applications, it offers straightforward installation where mortise locks are not feasible.
Advantages
- Simple surface-mount design enables quick and easy installation on most wooden doors and gates.
- Robust steel construction provides enhanced physical security against forced entry attempts.
- Reversible latch system allows compatibility with left-handed and right-handed door orientations.
- Supplied with matching strike plate for a complete locking solution, eliminating the need for additional hardware purchases.
- Slim form factor ensures minimal impact on door aesthetics; visible mounting may not suit all decorative preferences.
Specifications
- Zinc-plated or painted steel case with integrated locking mechanism ensures corrosion resistance and durability in daily use environments.
- Litto B1112 complies with standard safety norms applicable to European building hardware; suitable for indoor/outdoor protection when installed under shelter from direct rain exposure.
- Total lock body dimensions: approximately 110 mm (width) x 70 mm (height) x 22 mm (depth).
- Cylinder slot accepts most standard Euro-profile cylinders (not included); latch can be operated by handle or key according to configuration chosen at installation time.
How it works
The Litto B1112 is mounted directly onto the face of a wooden door using screws. By turning the key or operating the handle, users engage or retract the internal latch bolt, securing the door against unauthorized opening. The reversible design supports either opening direction during setup. Routine maintenance involves periodic cleaning of moving parts for optimal performance over time.
