Usage
The Litto B1112 surface-mounted lock is designed for securing wooden doors and gates in residential or light commercial settings, providing reliable mechanical protection where mortise locks are unsuitable.
Advantages
- Allows easy installation on wooden doors without the need for complex mortising.
- Zinc-plated steel construction ensures resistance to corrosion and wear over time.
- Reversible latch mechanism accommodates both left- and right-handed door configurations.
- Includes a bolt locking function for increased door security when needed.
- Slim, unobtrusive design fits most standard wooden doors and gates with minimal visual impact.
Specifications
- Zinc-plated steel case with hardened bolt components for durability; black epoxy paint finish on visible parts for enhanced weather resistance.
- Lifespan tested over thousands of operation cycles; designed in accordance with typical European building standards for surface locks used outdoors or indoors. No formal certification label present.
- Main case dimensions: approximately 110 mm x 90 mm x 24 mm. Bolt projection: up to 20 mm upon locking. Compatible with common euro-profile cylinders (not included).
- Cylinder not supplied—choose your preferred cylinder length as required by the installation depth. Lock is delivered complete with fixing screws and strike plate suitable for wood-frame mounting.
How it works
The Litto B1112 lock mounts directly onto the interior face of a wooden door or gate using provided screws. The latch engages automatically when closed, while the bolt can be extended via key or knob rotation to secure access as needed, ensuring straightforward operation day-to-day for most users.
