HS330 Van Beveren SS55 Stud Shim Diagram C GU Fitting for Lift and Slide Frames / pce

HS330 Van Beveren SS55 Stud Shim...

Estimated delivery date :  Wednesday 23 September
€7.74 HT
In stock

Ref : FGT-1631511

Quantity

Add to your shopping List

You must be logged


Description

Product

The HS330 Van Beveren SS55 Stud Shim Diagram C is a precision component designed for GU lift-and-slide frame fittings, ensuring accurate alignment and secure hardware installation.

Specifications

  • Engineered specifically for compatibility with HS330 Van Beveren SS55 lift-and-slide frame systems
  • Manufactured to meet the dimensional requirements of Diagram C configurations
  • Designed for use with GU fittings, ensuring consistent fit and reliable mechanical performance
  • Constructed from durable materials suited to the mechanical demands of lift-and-slide door hardware
  • Sold individually per piece, allowing targeted replacement or adjustment without full kit purchase

Usage

The stud shim is inserted during the installation or adjustment of lift-and-slide door frames to compensate for dimensional tolerances. It ensures proper stud positioning within the GU fitting assembly, maintaining smooth operation and correct alignment of the sliding door mechanism.

FAQ

  1. What is this shim used for? — It is used to adjust and align stud positioning within GU lift-and-slide frame fittings, specifically in HS330 Van Beveren SS55 Diagram C configurations.
  2. Is this component sold individually? — Yes, it is sold per piece, allowing precise quantity ordering for repair or installation needs.
  3. Which frame system is this shim compatible with? — It is compatible with HS330 Van Beveren SS55 lift-and-slide frame systems using GU fittings.
  4. Can this shim be used for new installations and replacements? — Yes, it is suitable for both new frame installations and replacement in existing lift-and-slide door assemblies.
  5. What does Diagram C refer to? — Diagram C refers to a specific configuration or geometry variant within the Van Beveren SS55 fitting range, defining the shim's dimensional profile and placement.
