Product
Angle bracket with pre-mounted clamp #1, black lacquered RAL 9005, designed for integration in Roto ALU 540i systems for wood, PVC, and aluminium frames. Suitable for frames weighing up to 90 or 130 kg, with LFF 405–600 mm and HFF 510–1200 mm. Ideal for use with most Belgian aluminium profiles.
Specifications
- Black lacquered finish (RAL 9005) for enhanced durability and aesthetic integration
- Pre-mounted clamp #1 for simplified installation
- Compatible with standard ALU 540i configurations, excluding SAPA RC-SystemS profiles
- Constructed for use with wood, PVC, and aluminium frames
- Supports maximum frame weight of 90 or 130 kg, depending on configuration
Usage
This angle bracket fits into the frame system to provide structural support and secure sash movement. Requires a compatible handle with accessories and an aluminium rod, which must be cut to size during installation. Designed for professional window and door manufacturing with most Belgian aluminium profiles.
FAQ
-
Which frame profiles is this angle bracket compatible with?
It is suitable for most Belgian aluminium profiles, including Aliplast, Reynaers, Van Beveren, and WICONA, but not SAPA RC-SystemS.
-
What is the maximum frame weight supported?
It supports frames up to 90 kg or 130 kg, depending on the specific installation parameters.
-
Are any additional accessories required?
Yes, a handle with accessories and an aluminium rod (to be cut to length) are required for complete installation.
-
Can this product be used for SAPA RC-SystemS profiles?
No, a different version or specific parts are needed for SAPA RC-SystemS profiles.
-
What are the minimum and maximum frame dimensions supported?
Suitable for frames with LFF (width) between 405–600 mm and HFF (height) between 510–1200 mm.
