Sensys 8645i 110° Nickel Quick-Mount Hinge (Ø10x6mm) with Soft Close and Self-Closing for Door

Usage

Designed for use on cabinet and furniture doors, the Charnière Sensys 8645i 110° nickel-plated quick-mount hinge with integrated damping and automatic closing is ideal for wood or composite panel doors in residential or commercial settings.

Advantages

• Quick clip-on assembly enables fast, tool-free installation and replacement.
• Integrated soft-closing technology ensures quiet, gentle door closure.
• Automatic closing function secures the door from a certain angle onward.
• 110° opening angle allows easy access to interior compartments.
• Durable nickel-plated finish provides corrosion resistance for long-term reliability.

Specifications

• The hinge features a cup diameter of Ø10x6mm, crafted from robust steel with a nickel finish using advanced Sensys damping technology.
• Tested for long service life and consistent performance; conforms to industry standards for stud hinges and accessories where applicable.
• Maximum opening angle: 110°. Cup depth: approximately 6 mm. Suited for standard door thicknesses in cabinetry applications. Quick-Fix mounting simplifies installation on doors with pre-bored holes (Ø10mm).
• The hinge includes an integrated damper mechanism built into the arm, supporting self-closing action without additional accessories. Designed specifically for overlay doors in furniture construction using the Sensys platform.

How it works

Once installed into a pre-drilled cup (Ø10x6mm) on the door, this hinge clips securely onto its baseplate. The integrated damper absorbs impact as the door closes, while an internal spring automatically draws the door shut after partial closure.
