UCS Sintesi 2000 White Chain Motor 230 Vac per piece

Usage

The UCS Sintesi 2000 chain drive motor in white is designed for automated opening and closing of windows. It is suitable for residential, commercial, or institutional buildings where controlled natural ventilation or remote window access is required.

Advantages

• Allows precise, automated control of window openings for improved air flow.
• Slim white design integrates discreetly into modern interiors.
• Electric operation at 230 Vac simplifies integration with building automation systems.
• Smooth and quiet chain mechanism minimizes noise during use.
• Reliable performance even on high or hard-to-reach windows; electrical supply required nearby may limit some installations.

Specifications

• The unit features a robust metal housing with a durable white finish and uses an internal stainless steel chain mechanism optimized for frequent operation.
• The product meets standard safety regulations for electric window operators and is designed for long-term use in various environments.
• The motor operates on a standard European voltage of 230 Vac. Typical thrust force ranges from approximately 200–400 N depending on the configuration, supporting most casement and skylight windows. Opening stroke lengths are user-selectable according to application needs (commonly up to several hundred millimeters).
• Differentiated by its compact profile, precise electronic limits adjustment, overload protection system, and compatibility with centralized control systems or environmental sensors (if equipped).

How it works

Once connected to mains power and mounted to the window frame, the Sintesi 2000 extends or retracts its internal chain when activated by wall switch or building management system. This movement pushes or pulls the sash uniformly open or closed without manual effort.
