Surface Mounted Control Desks EFF-EFF 7200-10 per piece
€350.62
Usage
The Eff Eff 5512-12 control unit is designed for monitoring and managing electric lock bolts, providing secure locking for access control systems in commercial, industrial, or public buildings.
Advantages
- Compatible with Effeff motorized lock bolt models (5511, 5522, 5523, 5525, and 5526)
- Allows programmable unlocking and automatic relocking via rotary switches
- Supports various installation methods: wall-mounted or DIN rail mounting
- Status monitoring through two externally visible LEDs (lock/door state)
- Cable length flexibility up to 100 meters for installation adaptability
Specifications
- Compact enclosure: dimensions of approximately 88 x 98 x 63 mm; weight circa 190 g; RAL 7035 housing color
- Suits indoor use (IP20), with an operating temperature range from 0°C to +40°C and storage from -20°C to +60°C
- Power supply voltage of 12–16 V AC/DC or stabilized 12 V DC; typical current consumption: controller at approx. 130 mA, motor lock at up to 1.2 A depending on model
- Differentiating features include programmable unlocking/relocking times (1–15 sec), manual overrides via external contacts, and dual outputs for external device integration
How it works
The control unit receives power and interfaces with motorized lock bolts. Programmable rotary switches let users define unlocking durations and relocking delays. Door status is displayed via LEDs while manual triggers support flexible access scenarios.
