Usage
The Tringle Horizontale for Hautau Tornado 200 E25mm-2750mm is designed for integration in pivot window systems, enabling secure horizontal locking across a wide sash width range in demanding residential and commercial applications.
Advantages
- Covers sash widths from 1,450 mm up to 2,750 mm, supporting large-format pivot windows
- Compatible with multiple PVC profile systems requiring a 25 mm backset
- Engineered for secure multi-point locking and reliable operation over time
- Facilitates easy cleaning and ventilation by enabling full sash rotation up to 180° when used with Tornado fittings
- The installation requires precise adjustment according to the window profile type; professional installation recommended
Specifications
- Zinc-coated steel construction with HAUTAU-Splus (Cr-VI-free) corrosion-resistant surface finish for enduring durability
- Suits sashes weighing up to max. 200 kg; conforms to EN standards (e.g., EN 14351-1) relevant for architectural fittings
- Sash width: suitable from approx. 1,450 mm up to maximum 2,750 mm as part of the Tornado system; fits profiles with a backset/entrée of 25 mm
- Differentiates itself by enabling integration into energy-efficient window systems (≥70 mm depth), ensuring all-round sealing and high security levels
How it works
This horizontal rod fits into the designated groove of compatible window profiles within the HAUTAU Tornado system. When actuated via the central handle or gear mechanism, it transmits motion evenly along its length—engaging multiple locking points—providing enhanced security and optimal sealing throughout wide pivoting windows.
