Product
Horizontal Bar for Hautau Tornado 200 E25mm-2350mm is a fitting designed for high-performance pivot windows, supporting sash widths from 650 mm up to 2350 mm and enabling stable and secure operation for large glass surfaces in residential or commercial projects.
Specifications
- Engineered for PVC and timber window profiles with an entry of 25 mm; compatible with multiple profile models such as Rehau BRILLANT DESIGN, VEKA SOFTLINE/TOPLINE 70, ALUPLAST IDEAL 4000, and others.
- Built for sash weights up to 200 kg, ensuring robust support and extended durability under demanding use.
- Features HAUTAU-Splus blue chromated surface (Cr-VI-free) for corrosion protection and longevity; includes both vertical and horizontal locking, adjustable length; comes with central locking gear, locking bolts, and security strikers.
- Allows 180° pivot for full window rotation, facilitating easy cleaning and safe operation.
- Available in white and black, matching varied architectural aesthetics.
Usage
Install the horizontal bar within the specific window profile system to provide secure central locking and reliable horizontal support for pivoting sashes. It is designed for both new and retrofit window applications, enabling smooth window rotation, safe suspension, and enhanced user convenience, with easy access for cleaning and ventilation.
FAQ
-
Which window profiles are compatible with this horizontal bar?
The product is compatible with Rehau BRILLANT DESIGN S799, VEKA SOFTLINE/TOPLINE 70, ALUPLAST IDEAL 4000, Kommerling EUROFUTUR, Thyssen PRESTIGE, DECEUNINCK 3001 ZENDOW, GEALAN 8000, KBE SYSTEM 70, SALAMANDER STREAMLINE 76, TROCAL INNONOVA 70, and Thyssen ELITE, among others using a 25 mm entry.
-
What is the maximum sash width and weight supported?
It supports sash widths from 650 mm to 2350 mm and sash weights up to 200 kg.
-
Does it offer features for ventilation and cleaning?
Yes, the 180° pivot mechanism allows for both night ventilation and easy cleaning of the window’s exterior.
-
Is the product suitable for both PVC and timber profiles?
Yes, it is designed for compatibility with both PVC and timber window systems with an entry of 25 mm and installation depths of 70 mm or more.
-
What accessories are included with the fitting?
The set includes the horizontal bar, central locking gear, locking bolts, security strikers, cover caps, adjustment elbow, and HAUTAU design handle.
