Roto Compass Set 931-1280mm (R.G24T) per piece
€92.45
In stock
Usage
The Rail de maintient de recouvrement Arrondi HKS S 9016 1650mm is designed for use in sliding doors and windows, providing secure overlay retention within ROTO fittings systems in residential or commercial environments.
Advantages
- Compatible with sash heights from 600 mm to 2350 mm, offering broad installation flexibility for various window and door sizes[1][2].
- Supports overlay widths of 18–20 mm, ensuring reliable coverage and proper fit[1][2].
- Suitable for profiles with a fitting axis of either 9 or 13 mm, increasing adaptability across different frame constructions[1][2].
- Works with maximum sash weights up to 100 kg, supporting robust applications without compromising stability[2].
- Simplified installation within the ROTO modular hardware system speeds up assembly and maintenance tasks[10].
Specifications
- Design & Materials: Manufactured as an overlay retention rail with an arched profile; intended for integration into ROTO sliding systems. Features precision metalworking to ensure durable performance.
- Sash Compatibility: For leaf heights between minimum of 600 mm and maximum of 2350 mm; compatible with overlays between 18–20 mm wide; fits sashes weighing up to 100 kg[1][2].
- Tolerance & Fit: Allows a rebate clearance (jeu en feuillure) of exactly 12 mm, optimizing smooth movement during operation while protecting against misalignment from frame flexing or temperature changes[1][2].
- Differentiating Feature: Supports both standard (9 mm) and reinforced (13 mm) hardware spindle axes—expanding use across multiple window/door profiles found in new builds or renovations[1][10].
- Chemical Finish & Appearance: Surface treatment enhances resistance to corrosion common to high-quality ROTO fittings; maintains structural integrity even under frequent operation or exposure [8][10].
How it works
The rail is mounted inside the overlay section of sliding doors or windows using standardized attachment points. It maintains consistent alignment during movement by securing the covering element against displacement, enabling reliable locking action in conjunction with other ROTO fittings components.
