Multipoint Lock AS4100 AN 5P Equiv F16/35/92/8 R001 Roller SKG / pce

Multipoint Lock AS4100 AN 5P Equiv...

Estimated delivery date :  Friday 24 July
€107.01 HT
In stock

Ref : FGT-1139231

Quantity

Add to your shopping List

You must be logged


Description

Product

The Multipoint Lock AS4100 AN 5P is a high-security multipoint locking system designed for residential and commercial doors, offering reliable protection with a roller bolt mechanism and SKG certification.

Specifications

  • Follower size: F16, backset: 35 mm, centers: 92 mm, bolt throw: 8 mm
  • Roller (Galet) bolt type for smooth and consistent engagement with the door frame
  • SKG certified, meeting recognized European security standards for multipoint locking systems
  • Compatible with standard door profiles requiring a 5-point locking configuration
  • Reference: R001, finish: AN (natural aluminum/silver tone)

Usage

Install the AS4100 multipoint lock into a door profile matching the F16/35/92/8 dimensions. The roller bolt engages multiple locking points simultaneously when the handle is lifted or the key is turned, distributing force across the door frame for enhanced security and a secure seal.

FAQ

  1. What does SKG certification mean for this lock? SKG is a Dutch quality and security certification indicating the lock meets tested resistance standards against forced entry, providing verified protection levels.
  2. What door profiles is this lock compatible with? This lock is designed for profiles with a 16 mm follower, 35 mm backset, 92 mm center distance, and 8 mm bolt throw.
  3. What is the bolt type on this multipoint lock? It features a roller (galet) bolt, which allows smooth engagement with the strike plate and reduces wear over time.
  4. How many locking points does this system provide? This is a 5-point multipoint lock, securing the door at five separate positions simultaneously.
  5. Can this lock be used on both left- and right-handed doors? Multipoint locks of this type are generally reversible; confirm compatibility with your specific door configuration before installation.
