GEZE mounting plate for TS 4000 E / TS 5000 E silver per piece
€35.92
In stock
Usage
The Geze TS 5000 E-FS door closer with Freeswing arm is designed for controlled and safe closing of fire and smoke protection doors in commercial, public, or institutional buildings where ease of access is essential.
Advantages
- Enables effortless door opening thanks to Freeswing function, ideal for barrier-free access.
- Integrated closing sequence control ensures reliable sealing of double-leaf fire and smoke doors.
- Supports adjustable closing force according to EN size 3–6 for flexible application across various door sizes.
- Complies with EN 1154/1155 standards and suitable for use on fire protection doors.
- Surface-mounted installation permits straightforward retrofitting without complex modifications.
Specifications
- Slim aluminum body in silver finish; features cam-action technology with standard arm (normal mounting).
- Cyclic durability tested over at least 500,000 cycles; certified under EN classifications such as EN 1154 / EN 1155 for safety on fire/smoke doors[1][4].
- Adjustable power from EN size 3–6: supports door widths from approximately 950 mm up to 1400 mm and weights up to 120 kg[1][4]. Maximum opening angle up to 180° when installation conditions permit[1].
- Differentiated by the integrated Freeswing mechanism that allows free movement during normal operation yet activates controlled closure during alarm or power loss. Additional functions: adjustable closing/latching speed, backcheck, delayed action timer (where equipped).
How it works
The Geze TS 5000 E-FS operates as a surface-mounted closer with a Freeswing arm—doors open freely without resistance under normal conditions. In case of an alarm or loss of electrical supply, the closer activates automatically to close the door securely as required by building safety regulations.
