Usage
The vertical rod for HAUTAU Tornado 200 is designed as a locking component for pivot windows, supporting sash heights from 1701 to 2200 mm. It is used in the assembly of HAUTAU Tornado window fittings to ensure secure and smooth operation within compatible profiles.
Advantages
- Enables safe locking and stable movement of large window sashes up to 200 kg
- Compatible with a wide range of PVC and timber window profiles
- Provides reliable sealing performance with integrated gasket solutions
- Facilitates easy cleaning by allowing full sash rotation (up to 180°)
- Covers adjustable height ranges, accommodating various architectural requirements
Specifications
- Zinc-plated steel construction with blue chromate surface finish, Cr-VI-free technology [4]
- Sash weight support up to max. 200 kg; certified performance for weather tightness: Class 9A (600 Pa) rain tightness, Class 4 (600 Pa) air permeability according to DIN EN standards [2][5]
- Suits sash heights between 1701–2200 mm; integrates into central locking gear ZV16 URZ systems [1][5]
- Differentiating features include two-stage sealing levels, thermal separation in hinges, and compatibility with both horizontal and vertical installations across multiple profile systems [3][4]
How it works
The vertical rod connects as part of the HAUTAU Tornado fitting set. When installed within compatible pivot or turn-and-tilt windows, it enables vertical locking action through engagement with central locking gears—helping securely open, close or lock large sashes while maintaining weather sealing integrity.
