Rivets standards alu / steel large head K14 GESIPA Ø5x12mm are robust, high-performance blind rivets designed for secure fastening in demanding applications. Supplied in packs of 250, they are suitable for professional use in metalworking, assembly, and construction.
These rivets are installed using compatible rivet pliers. The mandrel is long enough to accommodate nozzle extensions up to 10 mm, enabling access to hard-to-reach areas. After setting, the residual mandrel length inside the rivet enhances shear resistance, making them ideal for structural and load-bearing assembly tasks.
What materials are these rivets made from?
The body is made from high-grade aluminium alloy, and the mandrel is made from steel.
What is the diameter and length of these rivets?
Each rivet has a 5 mm diameter and a 12 mm length.
What head type do these rivets have?
They feature a large flange (K14) head with a 14 mm maximum head diameter for better load distribution.
Are these rivets compliant with industry standards?
Yes, they are manufactured according to DIN EN ISO standards for blind rivets.
What drill size should be used for installation?
A 5.1 mm drill hole is recommended for these rivets.
mvm-dt-2025-07-07
| Brand | Gesipa |
|---|---|
| Ø x L (mm) | 5 x 12 |
| Head | large |
| Rivetable thickness (mm) | 6,0 - 8,0 |
