Usage
This mechanism is designed for tilt-and-turn windows, allowing controlled opening, tilting, and secure closing. It is suitable for both wooden and PVC window frames requiring precise movement and reliable locking in diverse settings.
Advantages
- Easy surface mounting on the window frame
- 1600 mm rod accommodates a wide range of window sizes
- Patinated silver finish offers enhanced corrosion resistance and visual appeal
- Robust 44 BC/OB system ensures long-lasting operational reliability
- Smooth handle with three position stops (0°, 90°, and 180°) for flexible operation; requires periodic maintenance to preserve functionality
Specifications
- Mecanism includes central case with "L" lever handle, two end slides, two strikers, one bridge; treated steel components in patinated silver finish
- Treated materials provide durability; resists corrosion under regular use conditions; compatible with available extensions (14 mm risers) for specific installations[1][2]
- Total rod length: 1600 mm. Handle features three stable positions (0°, 90°, and 180°). Supplied with matching-finish screws[1][2]
- Differentiators include versatile mounting options and compatibility with various tilt-and-turn frames in wood or PVC[1][3]
How it works
The central case mounts to the sash while strikers attach to the fixed frame. The long rod connects via slides at each end. Operating the L-shaped handle engages or disengages locking points—enabling full opening, tilting ventilation mode, or secure closing according to selected position.
