Usage
The Accura drilling plate is designed for precise and repeatable drilling in sliding device installations, such as drawer runners or slides, within cabinetry and furniture assembly contexts.
Advantages
- Ensures accurate hole placement for reliable mounting of sliding systems
- Features integrated guide sleeves for controlled drill alignment and depth limitation
- Supports both metric and inch measurements for versatile installation requirements
- Intuitive setup reduces installation time compared to manual measuring methods
- Durable aluminum and plastic construction resists wear during repeated professional use
Specifications
- Anodized aluminum body with robust plastic components; guide sleeves included to fit ø5 mm HSS twist drill bits[1][4]
- Suits industry-standard System 32 layouts; compatible with ACURA universal drilling jig assemblies[3]
- Provides measurement accuracy along a rail up to a length of 500 mm; enables hole spacing from 64 mm upwards[1]
- Differentiated by its ability to limit drilling depth, preventing unintentional breakthrough of side panels[3]
How it works
The plate attaches securely to the ACURA jig’s rail system. Guide sleeves align the drill bit at predefined positions, allowing users to create exact holes for runners or slides. This set-up improves consistency across multiple installations while minimizing errors from manual marking or measuring.[3]
