Usage
The SAV Compas 150 Roto A et K 12/20-13 is designed for integration into tilt-and-turn or casement windows and doors made from wood, PVC, or aluminium frames. It is suitable for use in both residential and commercial buildings requiring robust window fittings.
Advantages
- Compatible with multiple materials: works with wood, PVC, and aluminium profile systems.
- High load capacity: supports sashes up to 150 kg for large or heavy windows and doors.
- Space-efficient design: minimal lateral (21 mm) and bottom (5 mm) encroachment enables installation in tight spaces[1].
- Simplified assembly: allows pre-positioning and fixation of bearings before frame assembly to streamline production[1].
- Reduces condensation risk at critical pivot points due to optimized drilling depth (5 mm)[1].
Specifications
- Design: Precision-engineered steel components with corrosion-resistant surface treatment. Includes narrow compass bearings and pivots compatible with modern frame geometries[1][6].
- Sustainability & Standards: Surface finishes exceed industry corrosion resistance requirements; suitable for long-term use even in challenging environments[6][10].
- Lifting Capacity: Supports maximum sash weight of up to 150 kg; facilitates opening angles up to a full 180° swing for wide ventilation access[1][6].
- Differentiating Features: Only requires a shallow bore depth on the frame (5 mm), fully pre-finishable before sash mounting, eliminating thermal bridges between bearing block and weather barrier[1]. Suitable for various profile cover widths including those requiring overlap seals.
How it works
The SAV Compas system installs onto the window sash and frame, permitting smooth rotational movement. It safely supports substantial weights while allowing tilt-and-turn operation or full casement opening. Bearings can be prepared prior to final assembly, simplifying installation workflows while ensuring reliable long-term function.[1][6]
