The BB Locks A1 Basic 60 SX electric lock is a high-security solution designed for permanent locking of swinging or pivoting doors, ensuring doors remain secured in critical environments such as banks, prisons, and data centers. With robust build quality and advanced sensing, it provides reliable access control for demanding applications.
Specifications
- Hardened symmetrical bolt with 20 mm throw, equipped with anti-saw pin for increased security
- Electromechanical action with Hall effect sensors for bolt and door position detection
- Compatible with 17 mm and 22 mm profile cylinders; mechanical override always possible, even under lateral pressure
- Adjustable, stainless steel covered strike plate included; available for backsets of 25, 30, 35, 50, and 60 mm
- 24 V DC operation (+/-5%), 2.2 A at locking activation, 130 mA holding current
- Complies with EN14846; fire tested for up to 60 minutes on timber door sets
- Signal outputs for bolt status, door status, cylinder activity, and handle use
- Electronics fully sealed in polyurethane resin for moisture protection
Usage
After the door closes, the lock's integrated Hall sensor detects the strike plate’s magnet, triggering the spring-loaded bolt to deploy and instantly lock. In case of power failure, the SX version remains locked, while mechanical unlocking is always available via the profile cylinder, maintaining high security under any condition.
FAQ
-
What happens to the lock during a power outage?
- The A1 Basic 60 SX remains locked in the event of a power cut, ensuring continued security.
-
What cylinder types are compatible with this lock?
- It accepts 17 mm and 22 mm profile cylinders for flexible integration.
-
Can the lock be mechanically unlocked if there is a malfunction or power loss?
- Yes, mechanical override is always possible using the profile cylinder, even if there is side pressure on the bolt.
-
What monitoring features does the lock provide?
- The lock offers signal outputs indicating bolt position (locked/unlocked), door position (open/closed), cylinder operation, and handle usage.
-
What door types and settings are supported?
- Suitable for single or double action swinging or pivoting doors in secure sites; the lock can be surface or mortise mounted and comes with an adjustable, reinforced strike plate.
